The Pınar Regulator and Hydroelectric Power Plant (HPP) Project is located in the Southeastern Anatolia Region, within the boundaries of Tut District of Adıyaman Province, on the Göksu River. The project area is situated to the south of the Tut District center, with the district located to the north between the regulator and the powerhouse.
The structures included in the project consist of the following components:
| Design Discharge | 50.00 m3/s |
|---|---|
| Number of Units | 3 units |
| Installed Capacity | 30.10 MW |
| Gross Head | 70.84 m |
| Total Energy | 137.60 GWh/year |
| Regulator Height | 7.00 m |
| Crest Length | 75.00 m |
| Transmission Channel Type | Trapezoidal Channel |
| Transmission Channel Length | 12,120.00 m |
| Penstock Diameter | 3.60 m |
| Penstock Length | 105.00 m |
